Model
Vibe SLICK S10
Rating
DIAM
10"
FS(Hz)
46.5
VAS(l)
30.9
QTS
0.52
PWR(W)
1000
SPL(dB)
88.4
IMP(Ohm)
4x1
avb
NOPROD
Parameter Thiele–Small
Fs(Hz)
46.5
Vas(l)
30.9
Qts
0.52
Qms
2.2
Qes
0.681
Bl(Tm)
10
Mms(gr)
65
Cms(mm/N)
0.182
Rms(kg/s)
8.566
Le(mH)
0
Re(Ohm)
3.6
Sd(sq.mm)
34600
Vd(l)
0
X-max(mm)
0
X-mech(mm)
0
Parameter Umum
Diameter (inch)
10
Daya Maksimum (W)
1000
Daya RMS (W)
350
Jumlah Coil
1
Impedansi Z-Nom (Ohm)
4
Efisiensi referensi η0(%)
0
Sensitivitas (dB) 1-W
88.4
Sensitivitas (dB) 2.8-V
0
Informasi Pemasangan
Speaker Displacement (l)
0
Diameter Total (mm)
0
Diameter Cutout (mm)
232
Kedalaman Pemasangan (mm)
126
Diameter Magnet (mm)
0
Enclosure Optimum
Enclosure
BP4, BP6P, Closed, Vented
