Alphard DEAF BONCE DB-315D1
Alphard DEAF BONCE DB-315D1
Model

Alphard DEAF BONCE DB-315D1

Rating
DIAM
15"
FS(Hz)
29
VAS(l)
138
QTS
0.48
PWR(W)
5000
SPL(dB)
88
IMP(Ohm)
1x2
avb
UNK

Thiele-Small Parameters

Fs(Hz)
29
Vas(l)
138
Qts
0.48
Qms
8.83
Qes
0.51
Bl(Tm)
28
Mms(gr)
1003
Cms(mm/N)
0.03
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
0
Sd(sq.mm)
0
Vd(l)
0
X-max(mm)
28
X-mech(mm)
0

General Parameters

Diameter (inch)
15
Max Power(W.)
5000
RMS Power(W.)
2500
Number of Coils
2
Impedance Z-Nom(Ohm)
1
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
88
Sensitivity(dB) 2.8-V
0

Mounting Information

Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
355
Mounting Depth (mm)
284
Magnet Diameter (mm)
0

Optimum Enclosures

Enclosures
Closed, Vented, BP4, BP6

Speaker response
