Model
American Bass XFL 1044
Rating
DIAM
10"
FS(Hz)
38.6
VAS(l)
9.7
QTS
0.42
PWR(W)
2000
SPL(dB)
82.7
IMP(Ohm)
4x2
avb
UNK
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
38.6
Vas(l)
9.7
Qts
0.424
Qms
5.6
Qes
0.459
Bl(Tm)
27.8
Mms(gr)
244
Cms(mm/N)
0.07
Rms(kg/s)
10.52
Le(mH)
0
Re(Ohm)
5.6
Sd(sq.mm)
31322
Vd(l)
0.548
X-max(mm)
18
X-mech(mm)
0
General Parameters
Diameter (inch)
10
Max Power(W.)
2000
RMS Power(W.)
1000
Number of Coils
2
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.12
Sensitivity(dB) 1-W
82.7
Sensitivity(dB) 2.8-V
84.3
Mounting Information
Speaker Displacement (l)
3.96
Total Diameter (mm)
0
Cutout Diameter (mm)
235
Mounting Depth (mm)
181
Magnet Diameter (mm)
196
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
