Model
American Bass XFL 1522
Rating
DIAM
15"
FS(Hz)
30.3
VAS(l)
63.3
QTS
0.49
PWR(W)
2000
SPL(dB)
86.8
IMP(Ohm)
2x2
avb
UNK
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
30.3
Vas(l)
63.3
Qts
0.494
Qms
4.216
Qes
0.56
Bl(Tm)
11.2
Mms(gr)
394
Cms(mm/N)
0.07
Rms(kg/s)
17.792
Le(mH)
0
Re(Ohm)
0.9
Sd(sq.mm)
81430
Vd(l)
1.55
X-max(mm)
19
X-mech(mm)
0
General Parameters
Diameter (inch)
15
Max Power(W.)
2000
RMS Power(W.)
1000
Number of Coils
2
Impedance Z-Nom(Ohm)
2
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
86.8
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
353
Mounting Depth (mm)
215
Magnet Diameter (mm)
196
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
