Model
Ascendant Audio CHAOS 15 D2
Rating
DIAM
15"
FS(Hz)
27.1
VAS(l)
119.1
QTS
0.46
PWR(W)
2000
SPL(dB)
88.7
IMP(Ohm)
2x2
avb
UNK
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
27.1
Vas(l)
119.1
Qts
0.46
Qms
6.62
Qes
0.494
Bl(Tm)
16
Mms(gr)
272
Cms(mm/N)
0.127
Rms(kg/s)
6.996
Le(mH)
0
Re(Ohm)
2.7
Sd(sq.mm)
81316
Vd(l)
1.708
X-max(mm)
21
X-mech(mm)
0
General Parameters
Diameter (inch)
15
Max Power(W.)
2000
RMS Power(W.)
1000
Number of Coils
2
Impedance Z-Nom(Ohm)
2
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
88.7
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
4.8
Total Diameter (mm)
0
Cutout Diameter (mm)
359
Mounting Depth (mm)
203
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
