Model
Audiopipe TS-CAR8
Rating
DIAM
8"
FS(Hz)
43
VAS(l)
13.9
QTS
0.49
PWR(W)
350
SPL(dB)
87
IMP(Ohm)
4x1
avb
UNK
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
43
Vas(l)
13.9
Qts
0.491
Qms
1
Qes
0.745
Bl(Tm)
9.4
Mms(gr)
67
Cms(mm/N)
0.204
Rms(kg/s)
18.16
Le(mH)
0
Re(Ohm)
3.6
Sd(sq.mm)
26000
Vd(l)
0.117
X-max(mm)
5
X-mech(mm)
0
General Parameters
Diameter (inch)
8
Max Power(W.)
350
RMS Power(W.)
175
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.14
Sensitivity(dB) 1-W
87
Sensitivity(dB) 2.8-V
87
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
2145
Cutout Diameter (mm)
183
Mounting Depth (mm)
105
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
