Model
Dibeisi DBS-BS1008
Rating
DIAM
10"
FS(Hz)
36.9
VAS(l)
35.8
QTS
0.6
PWR(W)
600
SPL(dB)
91
IMP(Ohm)
4x2
avb
PROD
Thiele-Small Parameters
Fs(Hz)
36.9
Vas(l)
35.8
Qts
0.603
Qms
4
Qes
0.71
Bl(Tm)
0
Mms(gr)
0
Cms(mm/N)
0
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
3.4
Sd(sq.mm)
33000
Vd(l)
0
X-max(mm)
0
X-mech(mm)
0
General Parameters
Diameter (inch)
10
Max Power(W.)
600
RMS Power(W.)
300
Number of Coils
2
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
91
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
0
Mounting Depth (mm)
0
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, BP4
