Model
DS18 Car Audio ELITE Z15
Rating
DIAM
15"
FS(Hz)
40.4
VAS(l)
51.3
QTS
0.75
PWR(W)
1800
SPL(dB)
88
IMP(Ohm)
4x2
avb
PROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
40.4
Vas(l)
51.3
Qts
0.75
Qms
6.881
Qes
0.842
Bl(Tm)
12.1
Mms(gr)
288
Cms(mm/N)
0
Rms(kg/s)
10.626
Le(mH)
0
Re(Ohm)
1.7
Sd(sq.mm)
81917
Vd(l)
2.498
X-max(mm)
31
X-mech(mm)
0
General Parameters
Diameter (inch)
15
Max Power(W.)
1800
RMS Power(W.)
900
Number of Coils
2
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
88
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
3.96
Total Diameter (mm)
0
Cutout Diameter (mm)
352
Mounting Depth (mm)
192
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, BP4
