DS18 Car Audio  Z-BD154D
DS18 Car Audio  Z-BD154D
Model

DS18 Car Audio Z-BD154D

Rating
DIAM
15"
FS(Hz)
37
VAS(l)
55.9
QTS
0.7
PWR(W)
1400
SPL(dB)
88
IMP(Ohm)
4x2
avb
PROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.

Thiele-Small Parameters

Fs(Hz)
37
Vas(l)
55.9
Qts
0.702
Qms
7.189
Qes
0.931
Bl(Tm)
20.7
Mms(gr)
296
Cms(mm/N)
0.061
Rms(kg/s)
9.587
Le(mH)
0
Re(Ohm)
5.8
Sd(sq.mm)
804
Vd(l)
0.016
X-max(mm)
20
X-mech(mm)
0

General Parameters

Diameter (inch)
15
Max Power(W.)
1400
RMS Power(W.)
700
Number of Coils
2
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
88
Sensitivity(dB) 2.8-V
0

Mounting Information

Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
356
Mounting Depth (mm)
167
Magnet Diameter (mm)
150

Optimum Enclosures

Enclosures
Closed, BP4

Speaker response
