Model
Jaycar CW-2110-8 (200MM) PAPER CONE WOOFER
Rating
Attention! Parameters of that speaker were not checked: a source of data, manual were not found.
DIAM
8"
FS(Hz)
39
VAS(l)
40.3
QTS
0.92
PWR(W)
60
SPL(dB)
84.5
IMP(Ohm)
8x1
avb
NOPROD
Thiele-Small Parameters
Fs(Hz)
39
Vas(l)
40.3
Qts
0.922
Qms
3.2
Qes
1.296
Bl(Tm)
5.8
Mms(gr)
24
Cms(mm/N)
0.69
Rms(kg/s)
1.84
Le(mH)
0
Re(Ohm)
7.4
Sd(sq.mm)
20300
Vd(l)
0
X-max(mm)
0
X-mech(mm)
0
General Parameters
Diameter (inch)
8
Max Power(W.)
60
RMS Power(W.)
30
Number of Coils
1
Impedance Z-Nom(Ohm)
8
Reference efficiency η0(%)
0.18
Sensitivity(dB) 1-W
84.5
Sensitivity(dB) 2.8-V
84.8
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
203
Cutout Diameter (mm)
185
Mounting Depth (mm)
85
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, BP4
