Model
JBL 1000GTI
Rating
DIAM
10"
FS(Hz)
62
VAS(l)
19
QTS
0.64
PWR(W)
600
SPL(dB)
86
IMP(Ohm)
4x1
avb
UNK
Thiele-Small Parameters
Fs(Hz)
62
Vas(l)
19
Qts
0.64
Qms
5.44
Qes
0.73
Bl(Tm)
10
Mms(gr)
59
Cms(mm/N)
0.112
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
3.2
Sd(sq.mm)
34500
Vd(l)
0.21
X-max(mm)
6
X-mech(mm)
0
General Parameters
Diameter (inch)
10
Max Power(W.)
600
RMS Power(W.)
300
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
86
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
3
Total Diameter (mm)
0
Cutout Diameter (mm)
229
Mounting Depth (mm)
110
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
