Model
JBL 1200GTI
Rating
DIAM
12"
FS(Hz)
37
VAS(l)
56.6
QTS
0.47
PWR(W)
1000
SPL(dB)
88
IMP(Ohm)
4x1
avb
UNK
Thiele-Small Parameters
Fs(Hz)
37
Vas(l)
56.6
Qts
0.47
Qms
4.89
Qes
0.52
Bl(Tm)
12.5
Mms(gr)
139
Cms(mm/N)
0.133
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
2.5
Sd(sq.mm)
54800
Vd(l)
0.3
X-max(mm)
5
X-mech(mm)
0
General Parameters
Diameter (inch)
12
Max Power(W.)
1000
RMS Power(W.)
600
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
88
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
284
Mounting Depth (mm)
108
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
