JBL 1500GTI
JBL 1500GTI
Model

JBL 1500GTI

Rating
DIAM
15"
FS(Hz)
35
VAS(l)
188.9
QTS
0.34
PWR(W)
1200
SPL(dB)
89
IMP(Ohm)
4x1
avb
UNK

Thiele-Small Parameters

Fs(Hz)
35
Vas(l)
188.9
Qts
0.34
Qms
5.8
Qes
0.36
Bl(Tm)
13.5
Mms(gr)
120
Cms(mm/N)
0.173
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
2.5
Sd(sq.mm)
87700
Vd(l)
0.48
X-max(mm)
5
X-mech(mm)
0

General Parameters

Diameter (inch)
15
Max Power(W.)
1200
RMS Power(W.)
600
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
89
Sensitivity(dB) 2.8-V
0

Mounting Information

Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
356
Mounting Depth (mm)
133
Magnet Diameter (mm)
0

Optimum Enclosures

Enclosures
Vented, BP6
