Model
JBL 800GTI
Rating
DIAM
8"
FS(Hz)
67
VAS(l)
7.8
QTS
0.53
PWR(W)
600
SPL(dB)
86
IMP(Ohm)
4x1
avb
UNK
Thiele-Small Parameters
Fs(Hz)
67
Vas(l)
7.8
Qts
0.53
Qms
4.8
Qes
0.6
Bl(Tm)
10.1
Mms(gr)
45
Cms(mm/N)
0.124
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
3.2
Sd(sq.mm)
21000
Vd(l)
0.13
X-max(mm)
6
X-mech(mm)
0
General Parameters
Diameter (inch)
8
Max Power(W.)
600
RMS Power(W.)
300
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
86
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
2
Total Diameter (mm)
0
Cutout Diameter (mm)
212
Mounting Depth (mm)
102
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Vented, BP6P
