Model
JBL GTO 529
Rating
DIAM
5"
FS(Hz)
94.7
VAS(l)
3.1
QTS
0.9
PWR(W)
135
SPL(dB)
85.8
IMP(Ohm)
3x1
avb
PROD
Thiele-Small Parameters
Fs(Hz)
94.7
Vas(l)
3.1
Qts
0.9
Qms
5.73
Qes
1.068
Bl(Tm)
3.8
Mms(gr)
10
Cms(mm/N)
0.294
Rms(kg/s)
0.997
Le(mH)
0
Re(Ohm)
2.7
Sd(sq.mm)
8660
Vd(l)
0
X-max(mm)
0
X-mech(mm)
0
General Parameters
Diameter (inch)
5
Max Power(W.)
135
RMS Power(W.)
45
Number of Coils
1
Impedance Z-Nom(Ohm)
3
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
85.8
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
119
Mounting Depth (mm)
54
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Vented, BP6P
