Model
Kicker 10CVT84
Rating
DIAM
8"
FS(Hz)
49.2
VAS(l)
10.3
QTS
0.56
PWR(W)
400
SPL(dB)
84.8
IMP(Ohm)
4x1
avb
NOPROD
Thiele-Small Parameters
Fs(Hz)
49.2
Vas(l)
10.3
Qts
0.565
Qms
10.641
Qes
0.597
Bl(Tm)
0
Mms(gr)
0
Cms(mm/N)
0
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
2.1
Sd(sq.mm)
0
Vd(l)
0
X-max(mm)
7
X-mech(mm)
0
General Parameters
Diameter (inch)
8
Max Power(W.)
400
RMS Power(W.)
200
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.2
Sensitivity(dB) 1-W
84.8
Sensitivity(dB) 2.8-V
90.7
Mounting Information
Speaker Displacement (l)
0.497
Total Diameter (mm)
216
Cutout Diameter (mm)
178
Mounting Depth (mm)
87
Magnet Diameter (mm)
133
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
