Model
Massive GTX124
Rating
DIAM
12"
FS(Hz)
40.2
VAS(l)
23.5
QTS
0.73
PWR(W)
1400
SPL(dB)
86.9
IMP(Ohm)
4x2
avb
PROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
40.2
Vas(l)
23.5
Qts
0.73
Qms
6.45
Qes
0.82
Bl(Tm)
11
Mms(gr)
232
Cms(mm/N)
0.07
Rms(kg/s)
9.1
Le(mH)
0.92
Re(Ohm)
1.7
Sd(sq.mm)
51000
Vd(l)
0.765
X-max(mm)
15
X-mech(mm)
25
General Parameters
Diameter (inch)
12
Max Power(W.)
1400
RMS Power(W.)
700
Number of Coils
2
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.18
Sensitivity(dB) 1-W
86.9
Sensitivity(dB) 2.8-V
87.9
Mounting Information
Speaker Displacement (l)
2.41
Total Diameter (mm)
305
Cutout Diameter (mm)
274
Mounting Depth (mm)
170
Magnet Diameter (mm)
229
Optimum Enclosures
Enclosures
Closed, BP4
