Model
MD.Lab SW-MD12
Rating
DIAM
12"
FS(Hz)
48.2
VAS(l)
35.6
QTS
1.09
PWR(W)
1500
SPL(dB)
86.6
IMP(Ohm)
4x2
avb
PROD
Thiele-Small Parameters
Fs(Hz)
48.2
Vas(l)
35.6
Qts
1.095
Qms
5.9
Qes
1.345
Bl(Tm)
10.5
Mms(gr)
157
Cms(mm/N)
0.07
Rms(kg/s)
8.05
Le(mH)
0
Re(Ohm)
3.1
Sd(sq.mm)
59882
Vd(l)
0
X-max(mm)
0
X-mech(mm)
0
General Parameters
Diameter (inch)
12
Max Power(W.)
1500
RMS Power(W.)
450
Number of Coils
2
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.29
Sensitivity(dB) 1-W
86.6
Sensitivity(dB) 2.8-V
90.7
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
316
Cutout Diameter (mm)
278
Mounting Depth (mm)
145
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, BP4
