Model
Morel MW168
Rating
DIAM
6"
FS(Hz)
44
VAS(l)
16
QTS
0.41
PWR(W)
300
SPL(dB)
86.1
IMP(Ohm)
8x1
avb
NOPROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
44
Vas(l)
16
Qts
0.41
Qms
2.1
Qes
0.509
Bl(Tm)
6.3
Mms(gr)
14
Cms(mm/N)
0.935
Rms(kg/s)
1.843
Le(mH)
0
Re(Ohm)
5.2
Sd(sq.mm)
11900
Vd(l)
0.042
X-max(mm)
4
X-mech(mm)
0
General Parameters
Diameter (inch)
6
Max Power(W.)
300
RMS Power(W.)
150
Number of Coils
1
Impedance Z-Nom(Ohm)
8
Reference efficiency η0(%)
0
Sensitivity(dB) 1-W
86.1
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
0
Cutout Diameter (mm)
0
Mounting Depth (mm)
0
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
BP6P, Vented
