Model
MTX T5515-04
Rating
DIAM
15"
FS(Hz)
21.4
VAS(l)
220.9
QTS
0.55
PWR(W)
600
SPL(dB)
87.2
IMP(Ohm)
4x1
avb
NOPROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
21.4
Vas(l)
220.9
Qts
0.55
Qms
4.85
Qes
0.63
Bl(Tm)
14.4
Mms(gr)
269
Cms(mm/N)
0.207
Rms(kg/s)
7.436
Le(mH)
0
Re(Ohm)
3.6
Sd(sq.mm)
87249
Vd(l)
1.175
X-max(mm)
13
X-mech(mm)
0
General Parameters
Diameter (inch)
15
Max Power(W.)
600
RMS Power(W.)
300
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.33
Sensitivity(dB) 1-W
87.2
Sensitivity(dB) 2.8-V
90.6
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
392
Cutout Diameter (mm)
352
Mounting Depth (mm)
193
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, BP4
