Noema 200ГДН37-8
Noema 200ГДН37-8
Model

Noema 200ГДН37-8

Rating
DIAM
12"
FS(Hz)
48
VAS(l)
80
QTS
0.44
PWR(W)
1000
SPL(dB)
94.7
IMP(Ohm)
8x1
avb
PROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.

Thiele-Small Parameters

Fs(Hz)
48
Vas(l)
80
Qts
0.44
Qms
11.6
Qes
0.46
Bl(Tm)
14.8
Mms(gr)
54
Cms(mm/N)
0.2
Rms(kg/s)
1.41
Le(mH)
0.9
Re(Ohm)
6.2
Sd(sq.mm)
53107
Vd(l)
0.239
X-max(mm)
5
X-mech(mm)
0

General Parameters

Diameter (inch)
12
Max Power(W.)
1000
RMS Power(W.)
200
Number of Coils
1
Impedance Z-Nom(Ohm)
8
Reference efficiency η0(%)
1.85
Sensitivity(dB) 1-W
94.7
Sensitivity(dB) 2.8-V
95.8

Mounting Information

Speaker Displacement (l)
2.9
Total Diameter (mm)
304
Cutout Diameter (mm)
286
Mounting Depth (mm)
132
Magnet Diameter (mm)
0

Optimum Enclosures

Enclosures
Vented, BP6

Speaker response
