Model
Orion HCCA124
Rating
DIAM
12"
FS(Hz)
33.2
VAS(l)
26.3
QTS
0.48
PWR(W)
10000
SPL(dB)
84.4
IMP(Ohm)
4x2
avb
PROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
33.2
Vas(l)
26.3
Qts
0.48
Qms
4.16
Qes
0.54
Bl(Tm)
33.2
Mms(gr)
386
Cms(mm/N)
0.06
Rms(kg/s)
19.356
Le(mH)
3.67
Re(Ohm)
7.4
Sd(sq.mm)
55990
Vd(l)
1.68
X-max(mm)
30
X-mech(mm)
0
General Parameters
Diameter (inch)
12
Max Power(W.)
10000
RMS Power(W.)
2500
Number of Coils
2
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.17
Sensitivity(dB) 1-W
84.4
Sensitivity(dB) 2.8-V
84.7
Mounting Information
Speaker Displacement (l)
8.212
Total Diameter (mm)
305
Cutout Diameter (mm)
292
Mounting Depth (mm)
261
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Closed, Vented, BP4, BP6
