Model
Pyle PLG54
Rating
DIAM
5"
FS(Hz)
80
VAS(l)
56.6
QTS
1
PWR(W)
200
SPL(dB)
96.9
IMP(Ohm)
4x1
avb
PROD
Some parameters have a deviation from parameters associated with them. Please, look at the exclamation marks to get advice.
Thiele-Small Parameters
Fs(Hz)
80
Vas(l)
56.6
Qts
1
Qms
6.5
Qes
0.9
Bl(Tm)
0
Mms(gr)
0
Cms(mm/N)
0
Rms(kg/s)
0
Le(mH)
0
Re(Ohm)
0
Sd(sq.mm)
0
Vd(l)
0
X-max(mm)
0
X-mech(mm)
0
General Parameters
Diameter (inch)
5
Max Power(W.)
200
RMS Power(W.)
100
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
3.11
Sensitivity(dB) 1-W
96.9
Sensitivity(dB) 2.8-V
0
Mounting Information
Speaker Displacement (l)
0
Total Diameter (mm)
130
Cutout Diameter (mm)
112
Mounting Depth (mm)
56
Magnet Diameter (mm)
0
Optimum Enclosures
Enclosures
Vented, BP6
