Pyle PLMRW8
Pyle PLMRW8
Model

Pyle PLMRW8

Rating
DIAM
8"
FS(Hz)
36.6
VAS(l)
34
QTS
0.43
PWR(W)
200
SPL(dB)
87
IMP(Ohm)
4x1
avb
PROD

Thiele-Small Parameters

Fs(Hz)
36.6
Vas(l)
34
Qts
0.434
Qms
3.2
Qes
0.502
Bl(Tm)
0
Mms(gr)
37
Cms(mm/N)
0.513
Rms(kg/s)
2.65
Le(mH)
0
Re(Ohm)
3.4
Sd(sq.mm)
21600
Vd(l)
0.119
X-max(mm)
6
X-mech(mm)
0

General Parameters

Diameter (inch)
8
Max Power(W.)
200
RMS Power(W.)
100
Number of Coils
1
Impedance Z-Nom(Ohm)
4
Reference efficiency η0(%)
0.32
Sensitivity(dB) 1-W
87
Sensitivity(dB) 2.8-V
90.8

Mounting Information

Speaker Displacement (l)
0
Total Diameter (mm)
245
Cutout Diameter (mm)
187
Mounting Depth (mm)
90
Magnet Diameter (mm)
0

Optimum Enclosures

Enclosures
Closed, Vented, BP4, BP6

Speaker response
